Width: 2.794 mm
Height: 6.223 mm
Length: 9.144 mm
Memory: EEPROM
Baud Rate: 300 to 38,400
Materials: ABS
Slew Rate: Fixed
Input Type: Digital
Input Range: Digital: ± 30 V
Output Signal: Voltage
Data Interface: RS485
Supply Voltage: 10 to 30 Vdc, 0.75 W
Analog I/O Note: Single channel analog output Voltage: 0 to 1V, ± 1V, 0 to 5V, ± 5V, 0 to 10V, ± 10V Current: 0 to 20 mA Input isolation to 500 V rms 12-bit measurement resolution Accuracy (integral and differential non-linearity): 0.1% FSR (maximum) Zero drift: ± 30 mV/°C (voltage output) ± 1.0mA/°C (current output) 1000 conversions per second Settling time to 0.1% FS 300 ms typical(1 ms maximum) Programmable output slew rate: 0.01V/s (mA/s) to 10,000 V/s (mA/s) (D4000 only) Autozero and autocalibration-no adjustment pots Voltage compliance: ± 12V Output current, short circuit current: 5 mA minimum, 10 mA maximum
Electrical Output: 0 to 10 Vdc
Output Resolution: Voltage: 12-bits
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Note: Unregulated 10V to 30 Vdc, 0.75 W maximum (voltage output), 1.0 W maximum (current output)
Supply Power Type: DC
Data Interface Note: Up to 124 modules with A1000 converter/repeater, 32 without A1000, User selectable channel address (via software command), ASCII format command/response protocol, Parity: odd, even, none, All communications setups (address, baud rate,parity) stored in nonvolatile memory using EEPROM, Checksum can be added to any command or response, Communications distance up to 10,000 feet with RS485 modules
Output Settling Time: 0.1% FS 300 ms Typical (1 ms maximum)
Electrical Connection: Screw Terminal
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Number of Channels, Input: Digital: 3
Number of Channels, Output: Voltage: 1
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
