Width: 72 mm
Height: 24 mm
Length: 120 mm
Weight: 200 g
Accuracy: ± 0.3 °C (± 0.5 °F) + 0.2 % rdg
RTD Type: 100 Ω Pt Sensor
Input Type: Thermocouple
Resolution: 0.1°C
Form factor: 3/64 DIN
Display Size: 14.2 mm (0.56 in)
Display Type: 3.5 Digit Single LED
Reading Rate: 2.5 samples/sec
Analog Output: 10 mV/deg
Step Response: 1 sec
Supply Voltage: 115 Vac
Cutout Dimensions: 22 x 68 mm
Display Type Note: 3 1 ⁄2 digit red LED, 14.2 mm (0.56") digits (optional green LED—no charge)
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: 2 W
Supply Power Note: 115 Vac, ±15%, 50/60 Hz (optional 230 Vac or non-isolated 9/26 Vdc—no charge)
Thermocouple Type: J
Additional Features 1: 230 Vac power
Operating Temperature, Max: 60 °C
Operating Temperature, Min: 0 °C
