Width: 97 mm
Height: 50 mm
Weight: 454 g
Accuracy: ± 0.01 %
Baud Rate: 75 to 9600
Functions: Range Programming: Solderless jumpers on rear of unit; select 200 mV, ±2V, ±20V, ±200V or 4 to 20 mA
Input Type: MA, MV, 10V
Form factor: 1/8 DIN
Display Size: 14.3 mm (0.56 in)
Display Type: 5 Digit LCD
Accuracy Note: ±0.01% of reading ±1 count of LSD
Output Detail: Standard dual form “A” relays rated 0.25 A @ 28V. Analog Output (Optional): 0 to 10 Vdc @ 2.5 mV resolution; 0V and 10V points are programmable via front-panel switches: maximum drive capability ±2 mA; the 4 mA and 20 mA points are programmable via front-panel switches; 4 to 20 mA output, maximum load 600 Ω
Sampling Rate: 3 Hz (3 updates/second)
Control Output: 2 SPDT Relay
Data Interface: RS232
Supply Voltage: 115 Vac
Conversion Rate: 3/sec
Number of Inputs: 2
Cutout Dimensions: 45 x 92 mm
Display Type Note: 5-digit, 7-segment, 14.3 mm (0.56") high LED Limit
Electrical Output: 0 to 10 Vdc
Number of Outputs: 1
Relative Humidity: 0 to 90% non-condensing
Supply Power Note: Power: Standard: 115 Vac (15 to 10%) @ 50 mA (47 to 500 Hz) Optional: 230 Vac (15 to 10%) @ 25 mA (47 to 500 Hz) Optional: 9 to 18 Vdc or 18 to 36 Vdc
Supply Power Type: AC
Common Mode Voltage: 1400 Vp (AC or DC) between analog output ground and AC power line ground
Data Interface Note: Serial Interface (Optional): ASCII RS232 or RS485 compatible; format: 1 start bit, 8 data bits, 1 stop bit and no parity bits
Programmable Functions: Range
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
