Width: 48 mm
Height: 24 mm
Weight: 60 g
Accuracy: ± 0.2 %
Polarity: Automatic, minus sign indicator
Input Type: Current, Voltage
Form factor: 1/32 DIN
Display Size: 10 mm (.39 in)
Display Type: 3.5 Digit Single LED
Reading Rate: 2.5 samples/sec
Accuracy Note: 0.2% ±1 count
Output Ripple: 0.1
Sampling Rate: 2.5 Hz (2.5 updates/second)
A/D Conversion: Dual-slope, average value
Supply Voltage: 10 to 30 Vdc
Number of Inputs: 1
Cutout Dimensions: 22.2 x 45 mm
Display Type Note: 3 1/2 digit, 0 to 1999; 7-segment, Red LED. Overrange: Positive = display blank, negative = “-” is displayed. Decimal Point: Jumper-selectable for 1.XXX, 1X.XX or 1XX.X.
Power Consumption: 0.6 W
Supply Power Note: Power: 10 to 30 Vdc, isolated
Supply Power Type: DC
Input Configuration: Bipolar single
Thermal Span Effect: < 50 ppm
Common Mode Rejection: 65 dB
Electrical Connection: Screw Terminal
Power Consumption Note: 0.6 W @ 24 Vdc
Temperature Coefficient: 2 µV/°C
Warm-Up to Rated Accuracy: 2 min
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
