Length: 101 mm
Weight: 200 g
Diameter: 22 mm
Mounting: Mounting Bracket
Approvals: CE
Bandwidth: Up to 1000 updates/second typical (± 3%)
Isolation: 2 MΩ @ 50 Vdc case to output terminations
Input Type: Voltage
Resolution: Up to 5.5
Input Range: 1 to 400 mV/V
Cable Length: 2 m
Output Signal: USB serial
ADC Resolution: 24 bit
Linearity Error: 0.001%/°C
Mating Connector: PT06F10-6S
Bridge Resistance: 350 to 15000 Ω
Sensor Excitation: 4.1 Vdc
Zero/Balance Error: 0.001%/°C
Electrical Connection: MIL-26482-I 10-6P, USB A
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -40 °C
Input Electrical Connection: MIL-26482-I 10-6P
