Accuracy: ± 0.19 inH2O
Approvals: General purpose, CE, RoHS
Insulation: TFE
Wire Gauge: 22 AWG
Switch Type: SPST
Cable Length: 2 ft
Probe Length: 2.3 in
Repeatability: ± 0.07 inH2O
Switch Rating: 50 VA @ 120 Vac
Number of Wires: 2
Specific Gravity: 0.8
Switch Operation: Dry switch closure, Selectable Normally Open or Normally Closed
Enclosure Ratings: IP68, NEMA Type 6
Materials, Wetted: PVDF
Media Compatibility: Oil, Solvents, Water
Operating Pressure, Max: 25 psi
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Operating Temperature, Max: 90 °C
Operating Temperature, Min: -40 °C
Material Construction Option: PVDF
