Width: 72 mm
Height: 35 mm
Length: 123 mm
Mounting: DIN-Rail or Wall Mount
Bandwidth: 500 Hz
Isolation: Input to Output Isolation: 3750 Vrms
Input Type: Digital
Digital Input: Digital (Wet contact): Low
Output Signal: Digital
Data Interface: Ethernet
LED Indicators: L1 (System Running): Yes, L2 (Ethernet Link/Act): Yes, L3 (Ethernet 10/100 M Speed): Yes, PoE: Yes
Supply Voltage: 12 to 48 Vdc
supply-voltage: 12 to 48 Vdc
Channel Current: 5.0A/channel at 25°C
Impedance Input: 10 kΩ
Digital I/O Note: Digital Input: Channels: 12 Contact: Wet contact Sink/Source (NPN/PNP): Sink/source On Voltage Level: 10 to 50 Vdc Off Voltage Level: 4 Vdc maximum Input Impedance: 10 kΩ Digital Output: :Channels: 6 Type: Isolated open collector Sink/Source (NPN/PNP): Sink Maximum Load Current: 100 mA/channel at 25°C (77°F) Direct drive power relay module Load Voltage: 5 to 30 Vdc Overvoltage Protection: — 60 Vdc Overload Protection: — 1.3 A Short-circuit Protection: — Yes Power-on Value: Yes, programmable Safe Value: Yes, programmable;Pulse Width: 1 ms
Electrical Output: Isolated open collector (Sink)
Power Consumption: 3 W
Relative Humidity: 10 to 90% RH, non-condensing
Supply Power Note: Power Requirements: Reverse Polarity Protection: Yes Powered from PoE: Yes, IEEE 802.3af, class1
Data Interface Note: Modbus TCP, Modbus UDP;Ethernet Port: 10/100 base-TX with Auto MDI/ MDI-Xwith PoE (Power over Ethernet);Watchdog: Dual: Yes, module (0.8 seconds), communication (programmable);Security: ID, Password and IP filter;Web HMI: Yes, I/O Pair Connection: Yes
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -30 °C
Number of Channels, Input: Digital: 12
Voltage Measurement Range: N/A
Number of Channels, Output: Digital: 6
Operating Temperature, Max: 75 °C
Operating Temperature, Min: -25 °C
