Area: 4.8 mm²
Length: 48 mm
length: 48 mm
Mounting: NPT
Materials: Brass
Wire Gauge: 20 AWG
Out Gassing: <0.003% VCM; <0.34% weight loss; sample at 125°C, cold surface at 25°C
Thread Size: 1/2 in
Fitting Model: Couple
Housing Flats: 22.4 mm
Pressure, Max: 120 psi
Vacuum Rating: 1 x 10^-8 torr
Number of Wires: 1
Alloy Material (+): Chromel
Alloy Material (-): Constantan
Leak Rate Under Vacuum: less than 10^⁻¹¹ cc He/s
Leak Rate Under Pressure: 1 x 10⁻⁶ cc air/s at 120 psi
Process Temperature, Max: 120 °C
Process Temperature, Min: -40 °C
