Length: 35.56 mm
Materials: Stainless Steel, NBR
Wire Gauge: 20 AWG
O-Ring, Max: 121 mm
O-Ring, Min: 2 mm
Out Gassing: <0.003% VCM
Fitting Model: Plate
Housing Flats: 38.1 mm
O-Ring Face R: 37.85 mm
Pressure, Max: 2000 psi
Thread Length: 19.05 mm
Vacuum Rating: 1 x 10^-8 torr
Number of Wires: 8
Out Gassing Note: <0.003% VCM; <0.34% weight loss; sample at 125°C, cold surface at 25°C
JAM NUT Thickness: 10.41 mm
Alloy Material (+): Copper
Alloy Material (-): Copper
Leak Rate Under Vacuum: less than 10^⁻⁸ cc He/s
Process Connection Size: 1 1/16 in
Process Connection Type: UNF Male
Across Flats Jam NUT HEX: 35.05 mm
Leak Rate Under Pressure: 1 x 10⁻⁶ cc air/s at 2000 psi
Process Temperature, Max: 120 °C
Process Temperature, Min: -40 °C
