Wire Gauge: 28 to 10 AWG
Cover Width: 2.2 mm
Amperage, Max: 0 A
Color Options: Gray
Terminal Width: 6.2 mm
Voltage Rating: N/A
Wire Size, Max: 4 mm²
Load Current, Max: 40 A
Circuit Protection: None
Cross-Section Area: 6 mm²
V/A/AWG Compliance: Voltage Rating (UL-cUL Ratings)=600 V;Voltage Rating (EN 50 019)=550 V;Voltage Rating (IEC 60 947-7-1)=800 V;Amperage, Max (IEC 60 947-7-1)=40 A;Amperage, Max (EN 50 019)=34/30 A;Amperage, Max (UL-cUL Ratings)=30 A;Wire Gauge (IEC 60 947-7-1)=28 to 10 AWG;Wire Gauge (EN 50 019)=24 to 10 AWG;Wire Gauge (UL-cUL Ratings)=20 to 10 AWG
Contamination Class: 3
Number of Terminals: 2
Rated Surge Voltage: 8 kV
Additional Features 1: spring clip TB
Compatible Wiring Note: Stranded Ferrule with Plastic Sleeve=0.25 - 2.5 mm²;Stranded with Ferrule without Plastic Sleeve=0.25 - 2.5 mm²;Stranded with Twin Ferrule with Plastic Sleeve=0.5 mm²
Insulation Strip Length: 10 mm
