Application: ON/OFF control
Number of phases: 1
Number of poles: 1
Mounting method: DIN rail
Terminal: Screw
LED indicator: X
Rated operational voltage, AC: 202-480 V
Operating voltage range, AC: 180-528 V
Rated operation current Ie at AC-1: 50 A
Rated load current Close mounting: 40 A
Permissible I²t value: 1800 A²s
Product Height (unpacked): 100 mm
Product Width (unpacked): 110 mm
Product Depth (unpacked): 100 mm
Supply voltage DC: 12-24 V
Control current max.: 7 mA
Must operate voltage max.: 9.2 V
Must release voltage min.: 1 V
Maximum operating temperature: 80 °C
Minimum operating temperature: -30 °C
Isolation: Phototriac
Switching at zero-crossing: ✓
