Application: ON/OFF control
Number of phases: 3
Number of poles: 2
Mounting method: Screw
Terminal: Screw
Complete with socket: X
LED indicator: ✓
Rated operational voltage, AC: 100-240 V
Operating voltage range, AC: 75-264 V
Rated operation current Ie at AC-1: 25 A
Permissible I²t value: 260 A²s
Applicable heater capacity (AC1: resistive load): 8.6 kW
Product Height (unpacked): 84.5 mm
Product Width (unpacked): 110.5 mm
Product Depth (unpacked): 105 mm
Supply voltage DC: 12-24 V
Control current max.: 10 mA
Must operate voltage max.: 9.6 V
Must release voltage min.: 1 V
Maximum operating temperature: 80 °C
Minimum operating temperature: -30 °C
Isolation: Phototriac
Switching at zero-crossing: ✓
Communication port(s): None
