ONMEAS AT9210 AC/DC Withstanding Voltage & Insulation Resistance Tester (AC 5.000kV/10mA; DC 6kV/5mA; DC 1kV/10GΩ)

Channels: Single channel

Test Functions: AC withstand voltage, DC withstand voltage, Insulation resistance

Interfaces: RS232/Handler

AC Withstand Voltage

Rated Output: AC 5.000kV/10mA

Output Voltage: 0.050kV-5.000kV AC Resolution: 1V

Measurement Current: 0.001mA-10.00mA Resolution: 0.001/0.01

DC Withstand Voltage

Rated Output: DC 6kV/5mA

Output Voltage: 0.050kV-6.000kV DC Resolution: 1V

Current Measurement: 0.1μA-5.000mA

Insulation Resistance

Rated Output: DC 1kV/10GΩ

Output Voltage: 0.050kV-1.000kV DC Resolution: 1V

Voltage Accuracy: 1% of reading + 2 digits

Measurement Range: 0.1MΩ-10GΩ <500V: 0.1MΩ-1GΩ, Accuracy: ±(10% of reading +5 digits); 1GΩ-10GΩ, for reference only ≥500V: 1MΩ-1GΩ, Accuracy: ±(5% of reading +5 digits); 1GΩ-10GΩ, Accuracy: ±(10% of reading +5 digits)

Instrument Dimensions: 270mm(W)x130mm(H)x450mm(D)

Net Weight: 8kg

Power Requirements: 110VAC~220VAC, 47Hz~63Hz, 300VA
