ONMEAS AT9310 AC/DC Withstand Voltage And Insulation Tester (1CH; AC 5.000kV/10mA; DC 6kV/5mA)

Channels: Single Channel

Test Functions: AC Withstanding, DC Withstanding, Insulation Resistance

Interfaces: RS232/Handler/Ethernet

AC Withstand Voltage

Rated Output: AC 5.000kV/10mA

Output Voltage: 0.050kV-5.000kV AC Resolution: 1V

Voltage Accuracy: 2% of reading + 5 digits

Voltage Regulation: 2% of reading + 5V (No Load to Full Load)

Output Frequency: 50Hz or 60Hz Selectable

Measurement Current: 0.001mA-10.00mA Resolution: 0.001/0.01

Current Accuracy: 2% of Reading + 5 digits

Voltage Rise Time: 0.1s-999.9s

Test Time: 0.2s-999.9s

Voltage Fall Time: 0.1s-999.9s

DC Withstand Voltage

Rated Output: DC 6kV/5mA

Output Voltage: 0.050kV-6.000kV DC Resolution: 1V

Voltage Accuracy: 2% of reading + 5 digits

Voltage Regulation: 2% of reading + 5V (No Load to Full Load)

Current Measurement: 0.1μA-5.000mA

Current Accuracy: 2% of reading + 5 digits

Voltage Rise Time: 0.1s-999.9s

Test Time: 0.2s-999.9s

Voltage Fall Time: 0.1s-999.9s

Insulation Resistance

Rated Output: DC 1kV/10GΩ

Output Voltage: 0.050kV-1.000kV DC Resolution: 1V

Voltage Accuracy: 1% of reading + 2 digits

Measurement Range: 0.1MΩ-10GΩ

Net Weight: 10kg

Power Requirements: 198V ~ 242V 50/60Hz400VA
