Main body
- Type: Upright
- Construction material: Aluminum die-cast
Head:
- Type: Binocular (Siedentopf)
- Inclination: 30°
- 360° rotating: Yes
- Interpupillary distance (mm): 48-75
- Dioptric adjustement: On left tube
- Tube inner diameter (mm): 23
Eyepieces:
- Field number (mm): 18
- Magnification: 10x
Nosepiece:
- Positions: Quadruple
- Reversed: Yes
- Bi-directional: Yes
- Rotation on ball bearings: Yes
Objectives
- Optical system: 160
- Parfocal distance (mm): 45
- Standard magnifications: 40x-1000x
- Type: N-PLAN
4x/0.10, W.D. 15.2mm
10x/0.25, W.D. 5.5mm
40x/0.65, W.D. 0.45mm
100x/1.25 (Oil/Water), W.D. 0.13 mm
Stage:
- Type: Double layer
- Dimensions (mm): 125x115
- Moving mechanism: Rack and pinion
- Moving range (mm): 70x30
- Material: Anti-scratch painting
- Specimen holder: Yes
- Slide number: 1
- X-Y movement: Yes
- X-Y Vernier scale: Yes
- Vernier scale accuracy (mm): 0.1
Power Supply for transmitted illumination
- Type: External
- Microscope connector: Jack, 2.1 mm
- Power plug type: Multi-plug (EU, UK, US)
- Input voltage: 100/240 VAC, 50/60 Hz
- Output voltage: 6 VDC 2.5A
Dimensions (HxWxD): 525x260x320mm
Weight (kg): 7.4
