Table Travel (X): 500 mm
Table Travel (Y): 400 mm
Table Travel (Z): 350 mm
Max. Workpiece Dimensions (WxD): 1100 x 630 mm
Max. Filling Height of Dielectric Tank: 260 mm
Distance Between Chuck to Table: 135 - 485 mm
Max. Workpiece Weight: 1350 kg
Max. Electrode Weight: 220 kg
Table Size (WxD): 800 x 450 mm
Machine Weight: 1950 kg
Generator
Max. Working Current: 60A
Overall Power Consumption: 6KVA
Weight: 320kg
Dielectric
Tank Capacity: 520L
Filter Density: 20 μm
Filter Elements: 3 pcs
