- Function and Applications:
Supplementary equipment set for the DEMO Set Electricity (15569-88). In combination with the set Electricity another 27 demonstration experiments can be performed:
Capacitor (3 experiments)
Diode (11 experiments)
Transistor (13 experiments)
- Benefits:
Continuing experiments from the field of electricity to the topic electronics
Provides insight into semiconductor technology and deep going comprehension of the functional principle of capacitor, diode and transistor
100-percent compatibility between teacher and student building blocks
Wiring diagram of the experiments can be completely illustrated
Rugged magnetically adhesive puzzle blocks featuring contrasted screen-printed electric symbol on top
The building blocks are easy to remove from experimental set-ups using the gripper rims
Safe electric contact is guaranteed by the use of a unique puzzle block system with corrosion-free gold plated contacts
Complete equipment set in addition to Electricity/Electronis 1
The equipment is stored in a robust aluminum case with removable lid
Foam insert for a quick control of completeness and secure transport of the set
Matched with international Curriculum: all topics are covered
Experiment guides for all experiments provided as PDF documents
Easy teaching and efficient learning through the digital experiment descriptions enclosed as QR codes
- Equipment and Technical Data:
The equipment set consists of all necessary components for the experiments
Robust storage case with foam insert fitting to the contained equipment
- Scope of delivery:
Junction, module DB: 09401-10, 2
Wire crossing, insulated, module DB: 09401-05, 1
Wire crossing,connected,module DB: 09401-06, 1
Resistor 500 Ohm,module DB: 09413-50, 1
Resistor 1 kOhm,module DB: 09414-10, 1
Potentiometer 10 kOhm,module DB: 09425-10, 1
Capacitor 10 nF,module DB: 09442-10, 1
Capacitor 47 nF,module DB: 09442-47, 1
Capacitor(ELKO)0.047 mF,module DB: 09445-47, 1
Capacitor(ELKO),0.1 mF,module DB: 09446-10, 1
Capacitor(ELKO),0.47 mF,module DB: 09446-47, 1
Silicon diode 1N4007,module DB: 09451-00, 1
Z-diode ZF 4.7,module DB: 09452-00, 1
Photodiode,module DB: 09453-00, 1
Light emitt. diode,red,module DB: 09454-00, 1
Bridge rectifier,module DB: 09455-00, 1
Bridge rectifier w. LED,module DB: 09455-01, 1
Transistor BC337,module DB: 09456-00, 2
Transistor BC327,module DB: 09457-00, 1
Phototransistor, module DB: 09458-00, 1
Transmitter f. opt. fiber,mod. DB: 09461-00, 1
Optical fiber, 2m: 09461-02, 1
Solar cell (2.5x5)cm,module DB: 09470-00, 2
Coil 400 turns, module DB: 09472-01, 1
Coil 1600 turns, module DB: 09472-02, 1
Clamp on holder: 02164-00, 1
Iron core, U-shaped, laminated: 07832-00, 1
Iron core, I-shaped, laminated: 07833-00, 1
Tightening screw: 07834-00, 1
Magnet, bar-shaped, d = 18 mm, l = 70mm: 06318-00, 1
- Necessary accessories:
DEMO Physics board with stand (02150-00)
DEMO advanced Electronics necessary accessories (15572-01)
DEMO advanced Physics Electricity/Electronics Building Block System, electricity (15569-88)
DEMO advanced Electricity necessary accessories (15570-01)
- Optional accessories:
Mobile Demo Lab for demonstration experiments with the a magnetic board (02190-93)
DEMO advanced Electromagnetism and induction (15571-88)
