Output Voltage( DC Max): 400V DC
Output Voltage(AC Max): 800Vp-p
DC Current(Max): 100mA
AC Current(Max): 200mAp-p
Output Power(Max): 40VA
Bandwidth: DC-400kHz(-3dB)
Slew Rate: 500V/μs
Output impedance: 10Ω
Protect resistor: 5kΩ/40watt
Safe Loading: ≧4kΩ/400V; 2.5kΩ/250V
Input Voltage upper limit: -5V~+5V(Max -10V~+10V)
AMPL: 100
OFFEST: ± 250V/ ± 400V
Monitor: 100:1
Output protection:
1. FUSE for output
2. Protection SW (switch)
3. OUTPUT short circuit, overload, overcurrent, overvoltage protection.
4. INPUT/OUTPUT input overvoltage protection
5. Over-temperature protection.
