Current output: 3 x 0~30A RMS
Max. output power: >450VA (30A output)
Input signal-Analog, Gain:
Standard: 0 ~ 7.07V RMS (±10Vpek), Gain: 4.5A/V
Option: 0 ~ 11.31V RMS (±16Vpek), Gain: 3A/V
Input signal -Digital (optional): support Aurora protocol
Current accuracy: 0.2%(0.5A-30A)
Current typical accuracy: <0.1%
Differential input impedance: 20k
Harmonic distortion ratio: ≤0.2%
Linearity: ≤0.2%
Phase accuracy: 0.2°
Frequency range: DC-5kHz±1dB
Step response: < 20us
Input/output delay: < 20us
Voltage output: 4 x 0~120V RMS
Max. output power: >60VA(120V output)
Input signal, Gain:
Standard: 0 ~ 7.07V RMS (±10Vpek), Gain: 20A/V
Option: 0 ~ 11.31V RMS (±16Vpek), Gain: 12A/V
Voltage accuracy: <0.1%(5V~120V)
Voltage typical accuracy: <0.05%
Differential input impedance: 20k
Harmonic distortion ratio: ≤0.1%
Linearity: ≤0.1%
Phase accuracy: 0.2°
Frequency range: DC-5kHz±1dB
Step response: < 20us
Input/output delay: < 20us
Power supply: 3 phase 380V AC 50/60 Hz
Chassis: 4U 19 inches
