General functions:
simultaneous receiver and transmitter testing
RF generator/analyzer, RF1 to RF8: 8 × SnapN, RF input/output to DUT
RF generator, TX AUX: 1 × SnapN, RF output
Receiver test functions:
RF generator signal is split and forwarded to 8 output ports
Every output can be switched off separately
Collective output level setting for connectors RF 1 to RF 8
Frequency-dependent attenuation (FDA) table for customer-specific corrections, separate for connectors RF1 to RF8
Transmitter test functions:
8 input signals to be multiplexed RF analyzer
Frequency-dependent attenuat (FDA) tables for customer-specific corrections, separate for connectors RF 1 to RF 8
RF generator
Frequency range: 70 MHz to 4000 MHz, up to 6000 MHz with the R&S®CMW-K046option
Frequency resolution: 0.1 Hz
Frequency uncertainty: same as timebase + frequency resolution
RF analyzer
Inherent spurious response:
Without input signal, 70 MHz to 6000 MHz, except 4000 MHz, 4800 MHz, 5162.5 MHz, 5600 MHz, 6000 MHz, except 100 MHz + n × 50 MHz with n = 0 to 62
Expected nominal power setting ≤ –10 dBm
Expected nominal power setting > –10 dBm
Power meter
Frequency range: 70 MHz to 4000 MHz, up to 6000 MHz with the R&S®CMW-K046 option
Frequency resolution: 0.1 Hz
Resolution bandwidths: Gaussian, 1 kHz to 10 MHz, in 1/3/5 steps, bandpass, 1 kHz to 30 MHz, in 1/3/5 steps, RRC, α = 0.1, 3.84 MHz, RRC, α = 0.22, WCDMA filter, 1.2288 MHz, CDMA filter
