II. Main technical specifications
1. Maximum load： 50kN
2. Measuring range： ≤40kN
3.Overload protection: Automatically protect when load is over 39kN
4. Measuring bias： ≤±0.1kN
5. Vertical deformation（flow value）： Range 0～20mm, bias ≤±0.05mm
6. Lifting rate for pressure machine： (50±5)mm/min
7. Communication port： RS232
8. Motor power： 550W
9. Power supply： AC220V±10%，50Hz
10.Overall power consumption: Less 800W
11. Ambient temperature： 0℃～60℃
12.Dimension： 650mm×380mm×840mm(L*W*H)
13.Net weight： 98kg
III. Optional accessories
1,Constant water bath： HWY-1 low temperature constant water bath(recommended）
