Specifications:
Measuring range: 3.18-653HBW, 5-3000HV
Test force: 9.807, 19.61, 24.52, 29.42, 49.03, 98.07, 196.1, 294.2N (1, 2, 2.5, 3, 5, 10, 20, 30kgf)
Max. height of test piece: 130mm
Depth of throat: 110mm
Magnifications of the measuring system: 500X, 125X (Eyepiece: 12.5X, Objective: 10X, 40X)
Min. scale value of the optical micrometer: 0.01um
Coordinate anvil: Dimension: 100x100mm
Travel: 25x25mm
Grade division of micrometer head: 0.01mm
Power supply: 220 AC or 110V AC, 50Hz
Dimensions: 490 x 330 x 760mm
Weight: approx. 88kg
Standard accessories:
Coordinate anvil: 1 pc.
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Tungsten carbide ball penetrator: Φ1, Φ2mm, 1 pc. each
Diamond pyramid penetrator: 1 pc.
Brinell standardized block: 2 pcs.
Vickers standardized block: 2 pcs.
Electronic calculator: 1 pc.
