Schaefer ProLine 240 EXTENDED Crimping Machine (0.05 ~ 6 mm², 20 kN)

Processable materials

Wire :Single wires

Wire cross section: 0.05 to 6 mm²

Terminals :Transversely belted stripes

Processing

Stripping lengths :< 10 mm

Sheath-removal lengths :> 10 mm

Performance and geometry

Drive: 0.75 kW three-phase motor

Motor speed: 440 – 2000 RPM

Pressing force :20 kN

Stroke: 40 mm

Closing height: 135.78 mm

Controls

HMI :STI 2015

Display: Touchscreen

Connection data and interfaces

Power supply :230 V, 50/60 Hz

Compressed air: 6 bar

Network :RJ-45

Dimensions and weight

Width x Depth x Height :1560 x 700 x 1950 mm

Weight :450 kg
