Exposure Range (gamma and x-rays): increments of .1mSv
Energy Dependence: ±10% maximum change in sensitivity for x and gamma ray energies from 16 keV to 8 MeV.
Electrical Leakage
In the absence of radiation, the dosimeters leakage or self discharge is less than 0.5% of full scale in 24 hours at 50°C. At 20°C dosimeters will read background radiation. After gross over exposure totaling up to 2000 R the leakage is less than 5% of full scale in 48 hours at 20°C. Thereafter, the leakage will decrease to original values.
Charging Voltage
Dosimeters are capable of being charged to “zero” with 140 to 195 volts.
Operational Characteristics
A maximum change in sensitivity of ±10% may occur under any probable combination of the following:
A) Temperature range below -20°C (-4°F)
or above +50°C (122°F)
B) Greater than 50,000 foot altitude for one month
C) Relative humidity greater than 95%
Highly resistant to shock and vibration.
Accuracy: ±10% of true dose for Cs137 or Co60 gamma.
Rate Response: Dosimeters are dose rate independent.
Enclosure Material: Barrel - carbon fiber-filled, high-strength, electrically-conducting plastic with metal clip.
Weight: Approx. 19 grams (0.7 oz.)
Size
Length: 11 cm (4.5 inches)
Diameter: 1.5 cm (0.6 inches)
Options
Protective sapphire lens
