Display: 7 inch touch screen
Processing range: 0.75–50mm²
Max. diameter of the conduit: Φ18mm
Stripping length: Front full stripping: 1–200mm; Front half stripping: 1–1500mm; End full stripping: 1–100mm; End half stripping: 1–300mm
Dimensions (L*W*H): 680*480*550mm
Net weight: 82kg
Cutting length: 1mm–999999.99mm
Cutting tolerance: ≤0.002*L (L = cutting length)
Blade material: High-quality high-speed steel
Productivity: 3500PCS/hour (depending on the length and size of the cable)
Drive mode: 16 rollers drive (feeding–stepper motor, blades–servo motor)
Wire feeding method: Belt feeding, no embossing or scratches on the cable
Lift operation mode: Digitally adjust the height of the pressure roller
Power supply: AC220V 50/60Hz; 110V 50/60Hz
Air source: 0.5Mpa
