Power supply: 200V–240V 50/60Hz
Air source: 0.4～0.6Mpa
Dimension: 850×550×1350mm
Net weight: 150KG
Applicable wire diameter: Φ0.8mm–Φ4mm
Max. Number of core wires: 12 core sheath wires
Min. Strip length for outer jacket: 2–4 core wire: 15mm / 5–10 core wire: 25mm
Applicable wire: AV, AVS, AVSS, CAVUS, KV, KIV, UL, IV Teflon, fiber wire, etc.
Stripping length: 1.0～10.0mm
Stripping tolerance: 0.05～0.1mm
Position tolerance: 0.05～0.1mm
Crimp terminal: open chain terminal; side feed & end feed
Crimping capacity: 2T
Press stroke: 30mm
Power: 1500W
Number of strokes: 5500PCS/hour
