Frequency Range: 400MHz ~ 4000MHz
Return Loss: 0 ~ 23dB
Max Input Power: 57dBm
Input VSWR: <1.1
Insertion Loss: ≤0.1dB
Directivity: ≥30 dB (<3GHz); ≥28 dB (>3GHz)
Test Mode: Segment Sweep / Single Normal / Single Burst
Segment Sweep Specification:
Frequency Range: 5M~3.6GHz
Frequency Resolution: 10KHz
Frequency Stability: ±2.5ppm
Filter Bandwidth (3dB): 1MHz
Power Range: 10~57dBm
Power Accuracy: ±0.8 dB
Power Measurement Specification:
Power Range: Average: 100mW ~ 200W (20 ~ 53dBm) Peak: 100mW ~ 500W (20 ~ 57dBm)
Peak Average Ratio: <12dB
CCDF: 0.1 ~ 100%
Power Resolution: ±0.01 dB
Power Accuracy: ±0.3dB (0℃ ~ +15℃ or +35℃ ~ +50℃ increase ±0.4dB)
(Single Normal): NOTE: lower 700MHz or higher 3300MHz, increase +3%
Burst Measurement Specification:
Burst Width: 30us ~ 80ms
Duty Cycle: 0.001-1
Min. Measurement Frequency: 12Hz
Average Burst Power: 100mW~200W or 20~53dBm
General Specification:
PC Connection: USB
RF Port: N-type female (50Ω)
Power Supply: USB Power: 5V, 500mA
Power Consumption: ≤ 2W
Working Temperature: 0℃ ~ 50℃
Storage Temperature: -20℃ ~ 70℃
Humidity: 0 ~ 95% (Non-condensing)
Weight: 495g
Dimensions: 130×(95)×124×34mm (H × W × T)
