Working voltage: 220V/50Hz
Power/grade: 50W and 500W double power switching
Control operation mode: PLC control, 7-inch color touch screen operation, with infrared remote controller
Gas pressure: 0.1MPa
Gas flow: 50W:105±5ml/min or 18±1mm;500W:965±30ml/min or 117±3 mm,flow meter adjustment
U type pressure gauge back pressure water column height: 50W:10mm; 500W:125±5 mm
Test angle: 50W: 0°,45°; 500W: 20°
Burning time: 0-9999X0.1S Can be preset
Burning times: 0-9999 times,Can be preset
Residual flame/Residual glow: 0-9999X0.1S Can be displayed
Test flame calibration: Temperature measuring copper head:50W:Ф5.5mm±0.01mm,weight before drilling 1.76 ± 0 .01 g;500W:Ф9mm±0.01mm,weight before drilling 10 ± 0 .05g
Thermocouple: The American original Omega φ0.5 armour nickel-chromium/nickel aluminum wire K-Thermocouple, temperature resistance 1100°
Distance between the bunsen burner port to temperature measuring copper block:50W: 10±1 mm; 500W: 55±1 mm
Flame height: 50W: 20±2mm(there is no internal and external flame); 500W: Inner flame:40±2mm,Outer flame:125±10mm
Temperature rise time from 100±2°to 700°±3°50W: 44±2S; 500W: 54±2S
Lighting: Equip with lighting in the test chamber, with control
Test chamber and dimension: > 0.75 cube, black inwall, with exhaust fan, dimension:1100*550*1200mm, 140kg
