Measurement range
Measurement pressure:(0~6)MPa
Measurement accuracy: ±0.02% FS
Output range
Output pressure: (0~6)MPa
Measurement accuracy: ±0.02% FS, ±0.05% FS
Working medium: Air or Nitrogen
External standard device: Range is not greater than the built-in pressure standard module, the external standard device range (0~2.5MPa, 0~1MPa, 0~600kPa, 0~250kPa), ±0.02% FS
External pressure source: 7MPa (optional)
Dimensions: (500 × 490 × 580) mm
Weight: 70kg
Control stability: ≤0.003% full scale
Pressure output stabilization time: Continuous output of more than 5 mins
Minimum controllable fineness adjustment: 0.1kPa
Screen size: 7-inch touchscreen display
Pressure input connector: M20 × 1.5 or NPT/BSP Male optional
Pressure output connector: Five M20 × 1.5 or NPT/BSP Female optional
Working environment: Ambient temperature (0~50)°C; Relative humidity ≤90%
Power supply: 220VAC
Dimensions: (600 × 350 × 210) mm
Weight: 17kg
