Test Applicable(Optional): IP X1~X9, X4K, X6K, X9K
Internal(WxDxH)mm: 1300 x 1200 x 1860
External (WxDxH)mm: 1800 x 1400 x 2400
Dripping Water (Vertical) X1: Water Flow：1+0.5 mm/min
Dripping Water(15°Tilt) X2: Water Flow：3+0.5 mm/min
Spraying Water X3
Water Flow：0~0.07 L/min
Spray Angel：60°
Splashing Water X4
Water Flow：0~0.07 L/min
Spray Angel：180°
Splashing Water X4K
Water Flow：0.6 L /min
Pressure：400 kPa
Water Jets X5: Water Flow：12.5±1 L/min
Powerful Water Jets X6: Water Flow：100±5 L/min
Powerful Water Jets X6K
Water Flow：75±5 L/min
Pressure：1000 kPa
Immersion X7: Round Type made by PVC, Thickness 20mm
Immersion: X8: Inside Diameter: 585mm, Height: 1500mm
High Temp. Water Jets (IEC) X9
Water Temp.：30~90℃(Adjustable)
Nozzle Distance：150~200 mm
High Temp. Water Jets (ISO) X9K
Water Temp.：30~90℃(Adjustable)
Nozzle Distance：100~150 mm
Oscillating Tube Radius (IPX3, IPX4): 200~1000 mm
Platform Rotating Speed: 0~17 RPM (Adjustable)
Power: 220/380 V 3Φ
