MAX ABSORBED POWER: 15 kW
ALUMINIUM WELDING WIRE DIAM:. 0,8- 1,2 mm
THREE PHASE MAINS VOLTAGE: 230 /400 V
ABSORBED POWER AT 60% 8,5 kW
FLUX CORED WELDING WIRE DIAM.: 1 -1,6 mm
MAINS FREQUENCY: 50 / 60 Hz
POWER FACTOR (cosphi): 0,9
BRAZING WIRE DIAM.: 0,8 - 1,2 mm
CURRENT RANGE: 40 - 350 A
ADJUSTMENT POSITIONS: 18
PROTECTION DEGREE: IP22
MAX CURRENT DC (EN 60974-1): 350 @35 % A
STEEL WELDING WIRE DIAMETER: 0,6 -1,6 mm
DIMENSIONS: 89 x 45,3 x 128,5 cm
DC CURRENT: 260 A
INOX WELDING WIRE DIAMETER: 0,8 -1,6 mm
WEIGHT: 101 kg
MAX NO LOAD VOLTAGE: 43 V
Included Accessories
ARGON GAS BOTTLE IT ADAPTOR - 432036
GAS REGULATOR 2 MANOMETERS 32 L\min - 722346
FEED ROLL 4R 0,6FE-0,8/0,9FE "P-K" - 742576
WORK CLAMP + CABLE 35MMQ 3M AX50 - 804217
MT36 MIG TORCH 3M - 742186
