Texas Instruments DS90UB633ARTVRQ1 Serializer 1M pixel ADAS 60-100 MHz PCLK serializer A 595-DS90UB633ARTVTQ1

Data Rate: 400 kb/s

Input Type: LVCMOS

Output Type: FPD-Link III LVDS

Mounting Style: SMD/SMT

Development Kit: DS90UB933-Q1EVM

Number of Inputs: 4 Input

Number of Outputs: 2 Output

Moisture Sensitive: Yes

Supply Voltage - Max: 1.89 V

Supply Voltage - Min: 1.71 V

Operating Supply Current: 76 mA

Operating Supply Voltage: 1.71 V to 1.89 V

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
