Cooling and heating
capacity
Capacity:
Condenser: Air-cooled
Process Heater: 1.7kW
Process Fluid Set Point Range: -85
to +50°C
Fluid Stability: ±0.5°C (at rated
load)
Pump
and process fluid
Pump: Gear
Process Fluid: HFE-7100 or equivalent
low temp. fluid
Wetted Materials: Standard
materials include copper, nickel, brass, and plastic. Optional: Fully stainless
steel
Flow Rate: 4 GPM (15.1 LPM) at 50
PSIG. Optional: Flow monitoring and control
Available Pressure: 50 PSIG (or
less), Optional: Pressure monitoring and control
Fluid Connections: 0.5” NPT
Controls
and compliance
User Interface: 5.7” color
touch-screen with temperature graphing and charting
Temperature Measurement: Range:
-210 to +680°C, Resolution: 0.1°C full scale
Remote Communications: Ethernet,
Serial-USB, Web server. Optional: RS-232
Alarms: Low Flow, Low Reservoir,
Out-of-temp Range. Optional: Drip Tray
Diagnostics: Runtime hours
(controller, chiller, compressor, pump), system performance log, valve
activation counts, enclosure temperature
Chiller Compliance: CE / RoHS /
designed to meet UL1995/UL61010
Operating
requirements
Ambient Temperature Range: 10 to
32°C (25°C nominal)
Power Requirement: 3-phase, 208
to 230v, 60Hz
System Dimensions (approx.): 22.0”W
X 42.0”D X 75.0" H (55.9 x 106.7 x 190.5cm)
