Input Supply Voltage: 36V to 60V DC
Maximum Supply Current: 1.5A
Open Circuit Output Voltage (Input 48V): -100V
Output Voltage Stability (max. load & supply variation): ± 1V
Short Circuit Current - Normal Drive: 213 ± 13 mA
Short Circuit Current - Hard Drive: 297 ± 35 mA
Alarm Level Range: -333 mA to + 333 mA
Alarm Level Stability (with load, supply and temperature variation): ± 2.5%
Alarm Contacts Rating: 100V 0.5A DC
Maximum Allowable Cable Power: 600V Peak Voltage; 4A Current
Operating Temperature Range: 0ºC to 40ºC
Surge Arrestor Rating
Max. Surge Current: 20kA
DC Spark Over Voltage: 700V
Impulse Spark Over Voltage: 1400V
