Wheel Diameter: Φ500 mm
Motor Power: 15 kW
Wheel Speed: 500–2500 rpm
Wheel Movement: Vertical / Horizontal / Segmented / Continuous / R-Axis Rotary Cutting / Angle Cutting (Optional)
Cut Types: Constant speed / Pulsing / Automatic speed adjustment
Vising Table Size: 832 × 728 mm
Maximum Cutting Diameter: Φ190 mm
Maximum Square Cross-Section: 190 × 360 mm
Travel Movement:
X-axis: 550 mm
Y-axis: 500 mm
Z-axis: 330 mm
R-axis: 360°
Features
1. Wheel Diameter: Φ500mm;
2. Rated power: 15kW;
3. Maximum cutting diameter: Φ190mm;
4. Freestanding independent water tank with a large capacity;
5. Enables multi-segment continuous cutting along the X-axis (R-axis), allowing either equal thickness (angle) sections or custom-specified positions;
6. Extra-large worktable and cutting chamber; the worktable measures 728x832mm, and the cutting chamber measures 1248x1220mm with a height of 900mm;
7. Equipped with a wireless handwheel, enabling four-axis control for quick alignment;
8. Integrated cast aluminum base with durable powder coating, ensuring robustness and rust resistance; equipped with a 10-inch large touchscreen;
9. Equipped with a 10-inch large touchscreen;
10. Freestanding independent water tank with a large capacity, easy to remove and clean;
11. Integrated magnetic separator, paper belt filtration system, and laser alignment for clean operation and precise positioning.
