Distance measurement:
Min. measuring range | Distance measurement: 0.05 m (0.16 ft)
Min. measuring range [m]: 0.05
Max. measuring range [m]: 70
Min. measuring range [ft]: 0.16
Max. measuring range [ft]: 230
Max. typical range: 70 m (230 ft)
Typical measuring tolerance: ±2 mm (± 0.08 in)
Inclination measurement:
Measuring range | Inclination measurement: 45 °
Accuracy to the laser beam: ±0.3°
Accuracy to the housing: ±0.3 °
Laser:
Ø of the laser point at distance 10 [mm]: 6
Ø of the laser point at distance 50 [mm]: 30
Ø of the laser point at distance 100 [mm]: 60
class: 2
output < [mW]: 1
Memory organisation:
Recall of previous measurements: 10
Device control:
Push buttons: ✓
Membrane keyboard: -
Touch: -
Interfaces:
Bluetooth: -
USB: -
Housing design: Plastics: ✓
Type of protection:
IP41: ✓
IP65: -
Power supply:
Internal via battery: -
Charging time [h]: -
Rated voltage [V]: -
Capacity [Ah]: -
Output voltage [V]: -
Charging current [A]: -
Internal (battery): 2 x 1.5 V, AA
Measurements per battery set: 5.000 ~ 8.000
Ambient conditions:
Operation - min. temperature [°C]: 0
Operation - max. temperature [°C]: 40
Storage - min. temperature [°C]: -20
Storage - max. temperature [°C]: 70
Dimensions:
Length (packaging excluded) [mm]: 27
Width (packaging excluded) [mm]: 49
Height (packaging excluded) [mm]: 118
Tiefe (packaging excluded) [mm]: 27
Weight: (packaging excluded) [kg]: 0.15
