Setting range: 5 / 1,000 mm (Rounds 5/10000 off)
Collimator optical system
f = 300 [mm]
D = 50 [mm]
Object to be inspected: Lens : f≒10 - 75 [mm]
Measurement item
(1) Focal position of lens
±⊿ｆ for standard focal position (0 standard)
(2) Contrast
Quantity of contrast for master lens
Sensitivity
Switchable
Low sensitivity SENS1 - SENS8 (Relatively bright lens)
High sensitivity SENS1 - SENS8 (Relatively dark lens)
Communication I / F: RS-232C compliant
Power-supply voltage: AC100V 50/60Hz
Power consumption [VA]: 150
Dimensions (WxHxD) [mm]
Measurement unit : 920 × 340 × 340
Display unit : 156 × 66 × 100
Weight [kg]: 61
