Setting range
Photosensitivity (3 levels)
Measurement time
Measurement pattern
Measurement resolution
Judgment criteria
Measurement range: Luminescence light quantity : 0.1 - 9999 [lx.s]
Supported OS: Windows7,10
Measurement time [ｍs]: 1 - 90
Communication I / F: RS-232C compliant or USB 2.0 compliant (option)
Power-supply voltage: AC100 - 240V 50/60Hz
Dimensions (WxHxD) [mm]
Main unit : 140 x 264 x 280
Light receiving part : 75 x 50 x 60
Weight [kg]: 6
Accessories
Light receiving part (1pcs)
Light receiving connection cable (1pcs)
Measurement item
Light exposure [lx･s] : Time integration value of flashing light luminescence
Guide No. [GN] : The proper value of the film sensitivity and the distance of the photography to a light exposure
Fno. [Fno.] : The proper value of Fno. to a light exposure
Aperture value [AV] : Iris diaphragm index
⊿EV [EV] : The deviation to the setting standard value
Maximum illuminance [lx] : Illuminance:Brightness of a surface lighted up by the light
Luminescence time [ms] : Time from start of emission of light to end of emission of light
