Camera Head
Camera Size: Φ23mm×155mm (Main body Φ23×51mm)
Camera Total Length: 155mm (include spring)
Sensor: 1/3" CMOS
Resolution: AHD 1920*1080
View Angle: 130°
Focus Distance: 15cm (approx)
Depth-of-Field: 20cm(approx)
Front Lens: Sapphire glass
Water-Proof: 20m Under Water(Camera fix on Cable)
Shell Material: Stainless steel
Lighting: Built-in 15×LED(White)
Operating Temperature: -10~50℃/+14~+122℉
Storage Temperature: -20~60℃/+4~+140℉
Cable Wheel
30M fiberglass rod cable
Dia. of push cable: 5.2mm
Material of cable: Fiberglass covered by PP
Operation: Mounted and rotatable in the case
LCD Monitor
Screen: 7-inch 16:9 Super bright HD color LCD screen
Resolution: 1024x600 pixels
Mirror and Flip: support image mirror, and flip
Video Resolution: AHD 1080P / CVBS D1
Video Encoding: H.264
Audio Recording: local sound record
Output: TV and Audio output
On-screen date and time
On-screen meter/ft. distance display(optional)
External memory: support SD memory card up to 64GB
Data output: USB 2.0 to PC
Language: Simplified Chinese, English, Traditional Chinese, Japanese, Korean, Russian, German, French, Italian, Spanish, Portuguese, Thai, Finnish, Swedish
Battery Supply
Power Supply: DC 12V input
Battery Capacity: 7.2V 6400mAh Li-on Battery
Power Output: 6-12V DC, USB 5V
Work/Charge time: 6/8 hours
