Safety ratings: CAT II 1000V, CAT III 600V
DC voltage (V): 200mV/2V/20V/200V/1000V; ±(0.05%+5)
AC voltage (V): 200mV/2V/20V/200V/1000V; ±(0.8%+25)
DC current (A): 2000μA/200mA/20A; ±(0.5%+4)
AC current (A): 2000uA/200mA/20A; ±(1.5%+15)
Resistance (Ω): 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ; ±(0.4%+5)
Capacitance (F): 200mF; ±(4%+50)
Conductance (ns): 200nS; ±(1.2%+50)
Frequency (Hz): 60MHz; ±(0.1%+3)
Temperature (℃): -40℃~1000℃; ±(1%+10)
Temperature (℉): -40℉~1832℉; ±(1.5%+10)
Audible/visual alarm: V/A/Cap/Diode
MAX/MIN: √
Peak Hold: √
LPF measurement: √
General Characteristics
Power: 1.5V battery (R03) x4
Display: 61mm x 36mm
Product net weight: 345g
Product size: 189mm x 89mm x 53mm
Standard accessories: Batteries, test lead, k-type temperature probe, English manual
