Technical Data
Display: 2.8” TFT (320×240)
IR resolution(Pixels): 160×120
Super resolution(Pixels): √ (320×240)
Spectral range: 8~14µm
Pixel size: 12µm
Frame rate: ≤25Hz
Thermal sensitivity(NETD): ≤50mK
Focus: Focus Free
Field of view(FOV): 40°(H) × 30°(V)
Spatial resolution(IFOV): 4.62mrad
Temperature measurement range: -20℃~550℃
Accuracy: ±2℃ or ±2% whichever is greater
Functions
Color palette: White Hot, Black Hot, Red Hot, Ironbow, Lava, Rainbow, Rainbow HC
Image mode: Thermal, Visual image, T-Mix fusion, PIP
On screen analyzer: 5 Points/3 Rectangles
HI/LO temperature alarm: LCD animation, LED flashlight, Buzzer
HI/LO temperature tracking: √
Digital camera resolution: 2MP
Video recording: √
Wi-Fi/Wi-Fi live streaming: √
LED lighting: √
Analysis software: PC+APP
General Characteristics
Battery: 5000mAh rechargeable Li-ion battery
Operating time: ≥8 hours
USB: Type-C
Storage: Built-in 32GB
Image/video storage format: JPG/MP4
Protection: IP65 & 2m drop proof
Certificates: CE, FCC, RoHS
Languages: EN, FR, DE, IT, ES, SV, PL, CZ
Weight: 600g
Dimension: 236mm×75.5mm×86mm
Packing Details
Standard accessories: Type-C USB cable, Quick Start Guide, Download Operation Guide
Standard individual packing: Gift box
Standard Qty per carton: 10pcs
Standard carton size: 500mm×315mm×295mm
Standard carton G.W.: 11.2kg
