Analogue Cable Tracing: Yes
Digitalized Cable Tracing: Yes
Tracing cables connected to ethernet hub with PoE support: Yes
Port Blink Test 10M/100M/1000M: Yes
Voltage Test: Yes
PoE Voltage Polarity Checking: Yes
PoE Voltage measurement: Yes
Crimping Crystal Test: Yes
Intelligent Wiremap indicate good connection, open, shorts and split Pairs: Yes
Continuity: Yes
Analogue Bargraph: Yes
Tracing signal transmission distance : 3Km
Vibration Indication: -
Loudness Adjustable: Yes
Sensitivity Adjustable: Yes
Flashlight: Yes
Remote Identification (Optional) : Max 15
Operation Indicator: Yes
Visual Fault Locator (Laser Beam Output): Power : 10mW; Flash Frequency : 1Hz / 2Hz / off: Yes
Optical Power Measurement*:
Wavelength (nm) : 850, 980, 1300, 1310, 1490, 1550, 1620
Detector type: InGaAs
mW / dBm: Yes
Accuracy : ±2%
Range: -70.00~6.00 dBm
Low Battery Indication: Yes
Auto Power Off: Yes
Cable Length Measurement:
Network Cable : 600m
Phone Line : 250m
Coaxial Cable : 200m
Best Accuracy: ±2m / ±2%
NCV: Yes
Cost Calculation : 100
Multimeter:
DC Voltage 600mV~1000V : -
AC Voltage 600mV~750V : -
DC Current 600mA~10A : -
AC Current 600mA~10A: -
Resistance 600Ω~60MΩ : -
Frequency 6Hz~60MHz : -
Capacitance 6nF~60MF: -
Diode: -
Continuity: -
Input Jack Indicators: -
Display : 3.2” 240x320 Dot Matrix
Auto Power Off: Yes
Power by : Main: 3.7V 1500mAH Lithium ion; Receiver: 3.7V 800mAH Lithium ion
