Analogue Cable Tracing: Yes
Digitalized Cable Tracing: Yes
Tracing cables connected to ethernet hub with PoE support: Yes
Port Blink Test 10M/100M/1000M: Yes
Voltage Test: -
PoE Voltage Polarity Checking: Yes
PoE Voltage measurement: Yes
Crimping Crystal Test: Yes
Intelligent Wiremap indicate good connection, open, shorts and split Pairs: Yes
Continuity: -
Analogue Bargraph: Yes
Tracing signal transmission distance : 3Km
Vibration Indication: Yes
Loudness Adjustable: Yes
Sensitivity Adjustable: Yes
Flashlight: Yes
Remote Identification (Optional) : Max 15
Operation Indicator: Yes
Visual Fault Locator (Laser Beam Output): Power : 10mW; Flash Frequency : 1Hz / 2Hz / off: Yes
Optical Power Measurement*:
Wavelength (nm) : 850, 980, 1300, 1310, 1490, 1550, 1620
Detector type: InGaAs
mW / dBm: Yes
Accuracy : ±2%
Range: -70.00~6.00 dBm
Low Battery Indication: Yes
Auto Power Off: Yes
Cable Length Measurement:
Network Cable : 600m
Phone Line : 250m
Coaxial Cable : 200m
Best Accuracy: ±2m / ±2%
NCV: Yes
Cost Calculation : 100
Multimeter:
DC Voltage 600mV~1000V : ±(0.5%+0.3)
AC Voltage 600mV~750V : ±(0.8%+0.5)
DC Current 600mA~10A : ±(1%+0.4)
AC Current 600mA~10A: ±(1%+0.5)
Resistance 600Ω~60MΩ : ±(2%+0.6)
Frequency 6Hz~60MHz : ±(2%+0.6)
Capacitance 6nF~60MF: ±(1%+0.1)
Diode: Yes
Continuity: Yes
Input Jack Indicators: Yes
Display : 3.2” 240x320 Dot Matrix
Auto Power Off: Yes
Power by : Main: 3.7V 1500mAH Lithium ion; Receiver: 3.7V 800mAH Lithium ion
