Basic Function
Power consumption: 750W (MAX)
Input voltage
AC (100V/110V/120V/220V/230V/240V)
50/60Hz (optional)
Display mode: LED screen display
Heating & soldering station
Power consumption: 700W (MAX)
Temperature range: 100–500°C (212°F–932°F)
Air pump type: Fan type
Noise: <52dB(A)
Air flow: 120L/min (MAX)
Electrical soldering station
Power: 70W (MAX)
Temperature range: 200–480°C
Temperature stability: ±2°C (still air and no load)
Temperature accuracy: ±15°C
Impedance of welding tip to ground: <2Ω
Voltage of welding tip to ground: <2mV
Heating core: Four-core stainless steel heating core
Working voltage of heating core: 24DC
Overall dimensions of unit: 167(L) * 100(W) * 131(H) mm
Weight: 1.86KG
USB port: 5V and 2A (max)
