Width: 0.5 mm
Height: 0.35 mm
Length: 1 mm
Lens Color: Yellow
Lens Shape: Rectangular
Unit Weight: 0.700 mg
Power Rating: 70 mW
Viewing Angle: 130 deg
Mounting Style: SMD/SMT
Lens Transparency: Non-Diffused
Illumination Color: Cool White
Luminous Intensity: 90 mcd
Moisture Sensitive: Yes
If - Forward Current: 5 mA
Vf - Forward Voltage: 2.9 V
Wavelength/Color Temperature: 7000 K
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 30 C
