AC Current Output:
6-phase current output per phase (effective value): 0 ~ 30A, output precision 0.2
3-phase current output per phase (effective value): 0 ~ 60A
6-phase parallel current output (RMS): 0 ~ 180A
Phase current long-term allowable working value (RMS): 10A
Maximum output power of phase current: 300VA
6-phase parallel current maximum output power: 1000VA
Allowable working time for maximum output of 6-phase parallel current: 10s
Frequency range (fundamental): 0 ~ 1000Hz
Harmonic frequency: 1 ~ 20
DC Current Output:
Current output: 0 ~ ±10A/phase, output accuracy 0.5 level
Maximum output load voltage: 20V
AC Voltage Output:
Phase voltage output (RMS): 0 ~ 120V, output precision 0.2
Line voltage output (RMS): 0 ~ 240V
Phase voltage/line voltage output power: 80VA/100VA
Frequency range (fundamental): 0 ~ 1000Hz
Harmonic frequency: 1 ~ 20
DC Voltage Output:
Phase voltage output amplitude: 0 ~ ±160V, output accuracy 0.5
Line voltage output amplitude: 0 ~ ±320V
Phase voltage/line voltage output power: 70VA/140VA
Switching Value:
8 switch inputs: Null contact 1 ~ 20mA, 24V
Potential contact access “0”: 0 ~ +6V; “1”: +11V to +250V
4 pairs of switching outputs: DC 220V / 0.2A; AC 220V / 0.5A
Time Measuring Range:
Time measuring range: 0.1ms ~ 9999s
Measurement accuracy: < 0.1ms
Dimensions: 375 × 350 × 180 mm³
Weight: 17kg
