Channel No.: 1
Input Range: Voltage/IEPE: ±10V, Charge: ±10⁶ pC
Sensitivity Uniformization: 0.100 ~ 999
Gain (mV/pC): 0.01 ~ 1000 (20dB)
High–pass Filters (Hz):
A: 0.3, 1, 3, 10, 30, 100
V: 1, 3, 10, 30, 100
D: 1, 3, 10, 30, 100
Low–pass Filters (kHz): 0.3, 1, 3, 10, 30, 100
Accuracy (%): A: ±1; V: ±3; D: ±3
Noise (µV): ≤5
Output Range (V): ±10
Power Supply: 220V 50Hz 0.1A or 110V 60Hz 0.2A
Operating Temperature (℃): −10 ~ +50
Weight (kg): 1.3
Size (mm): 45×122×200
