Channel No.: 1
Input Range: Voltage: ±10V, Charge: ±10⁶ pC
Sensitivity Uniformization: 1.00 ~ 1099
Gain (mV/pC): 0.01 ~ 1000 (20dB)
High–pass Filters (Hz): 0.3, 1, 3, 10, 30, 100
Low–pass Filters (kHz): 0.3, 1, 3, 10, 30, 100
Accuracy (%): ±0.5
Noise (µV): ≤5
Output Range (V): ±10
Power Supply: 220V 50Hz 0.1A or DC ±18V ~ ±27V
Operating Temperature (℃): −10 ~ +50
Weight (kg): 1.5
Size (mm): 70×132×200
