Bias Power BPSX 1-14-50 AC-DC Power Modules 1W 14V, 5V DUAL 85-265V Extreme Temp
Manufacturer: Bias Power Model: BPSX 1-14-50 - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0345.689.536
Width: 23.24 mm
Height: 13.97 mm
Length: 27.94 mm
Industry: Industrial
Unit Weight: 23.375 g
Output Power: 1 W
Input Voltage: 85 VAC to 265 VAC
Mounting Style: PCB
Input Frequency: 50 Hz/60 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 2 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 71 mA
Output Current-Channel 2: 28 mA
Output Voltage-Channel 1: 14 VDC
Output Voltage-Channel 2: 5 VDC
