Carling Technologies BA1-B0-34-630-221-D Hydraulic-Magnetic CIRCUIT BREAKER HYMAG
Manufacturer: Carling Technologies Model: BA1-B0-34-630-221-D - Contact
See more: Equipment Calibration-Inspection & Repair Service
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222) 730.39.68
Hai Phong city: (0225) 730.03.89
HCM city: (028) 38.119.636
Dong Nai: 0932.160.940
Width: 19.18 mm
Height: 50.8 mm
Length: 43.94 mm
Illuminated: Non-Illuminated
Unit Weight: 65 g
Actuator Type: Handle
Current Rating: 30 A
Mounting Style: Panel Mount
Voltage Rating: 277 VAC, 80 VDC
Number of Poles: 1 Pole
Termination Style: Screw
Voltage Rating AC: 277 VAC
Voltage Rating DC: 80 VDC
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
